Installing the NVMe M.2 SSD optionInstalling the NVMe M.2 SSD option
IMPORTANT: IMPORTANT: When installing the M.2 SSD adapter card, the top slot of the PCI cage is preferred as slot 1.
PrerequisitesPrerequisites
Before you perform this procedure, make sure that you have the following items available:
T-15 screwdriver
Philips screwdriver
NVMe SSD module
ProcedureProcedure
1. Power down the system .
2. Remove the blade, if installed.
3. Remove the access panel .
4. Using a Torx screwdriver, remove the three black T-15 Torx screws.
5. Lift the PCIe riser cage using the finger hold positions in the riser cage.
6. Remove the slot blank from the PCI cage.
