HP HPE Edgeline EL1000 User Manual

Mini-PCIe module port-cable mappingMini-PCIe module port-cable mapping
Table 1: LTE module port-cable mappingTable 1: LTE module port-cable mapping
LTE module cable portLTE module cable port Cable colorCable color Antenna connectorAntenna connector
Port 1 Black Antenna connector 1
Port 2 White (not used) Reserved
Port 3 Grey Antenna connector 3
Table 2: WiFi module port-cable mappingTable 2: WiFi module port-cable mapping
WiFi module cable portWiFi module cable port Cable colorCable color Antenna connectorAntenna connector
Port 4 Red Antenna connector 4
Port 4 Blue Antenna connector 5
Mini-PCIe module port-cable mapping 17
