HP HPE Edgeline EL1000 - Right Side Components

164 pages

To Next Page

To Previous Page

Right side componentsRight side components

ItemItem DescriptionDescription

1 Antenna connector 1 (LTE/3G/4G)

2 Antenna connector 4 (WiFi)

3 Reserved

4 Antenna connector 5 (WiFi)

5 REF in connector

6 REF out connector

7 Antenna connector 3 (LTE/3G/4G)

8 Power supply

Right side components 16
