Front panel componentsFront panel components

ItemItem DescriptionDescription

1 iLO port

2 Network port 1

3 Network port 2

4 USB 3.0 ports

5 Drives

6 Blade

Network connections are available in 1G and 10G. The 1G is shown.

Front panel components 9
