HP HPE Edgeline EL1000 User Manual

Power supply specificationsPower supply specifications
HPE 500W Flex Slot Platinum Hot Plug Power SupplyHPE 500W Flex Slot Platinum Hot Plug Power Supply
Input voltage range (V rms) 100-240
Frequency range (Nominal) (Hz) 50-60
Nominal input voltage (V rms) 100 120 127 200 208 220 230 240
Maximum rated output wattage rating
(Watts)
500 500 500 500 500 500 500 500
Nominal input current (A rms) 5.6 4.6 4.3 2.7 2.6 2.5 2.4 2.3
Maximum rated input wattage rating
(Watts)
558 550 543 539 538 538 537 537
Maximum rated VA (Volt-Amp) 564 556 549 544 544 543 542 542
Efficiency (%) 89.6 90.9 92.1 92.8 92.9 93.0 93.1 93.1
Power factor 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99
Leakage current (mA) 0.32 0.38 0.40 0.63 0.65 0.69 0.72 0.75
Maximum inrush current (A peak) 30 30 30 30 30 30 30 30
Maximum inrush current duration (ms) 10 10 10 10 10 10 10 10
Maximum British Thermal Unit rating
(BTU-Hr)
1904 1877 1853 1839 1837 1834 1832 1832
HPE 800W Flex -48VDC Hot Plug Power SupplyHPE 800W Flex -48VDC Hot Plug Power Supply
Input voltage range (V DC) -40 to -72
Frequency range (Nominal) (Hz) DC
Nominal input voltage (V DC) -40 -48 -72
Maximum rated output wattage rating
(Watts)
800 800 800
Nominal input current (A DC) 22.0 18.1 11.9
Maximum rated input wattage rating
(Watts)
882 871 858
Maximum rated VA (Volt-Amp) 882 871 858
Efficiency (%) 90.7 91.9 93.2
Power factor 1.0 1.0 1.0
Leakage current (mA) 0.0 0.0 0.0
Maximum inrush current (A peak) 30 30 30
Maximum inrush current duration (ms) 10 10 10
Maximum British Thermal Unit rating
(BTU-Hr)
3008 2971 2929
Power supply specifications 146
