Mechanical specificationsMechanical specifications

SpecificationSpecification ValueValue

Length 87.4 mm (3.44 in)

Width 338 mm (13.30 in)

Depth 234 mm (9.20 in)

Weight 7.5 kg (16.53 lb)

Mechanical specifications 145
