Accessing the System Utilities menuAccessing the System Utilities menu
To complete these steps, you need the HPE USB-to-serial cable (HPE part number 871947-B21).
Table 3: Settings for connecting USB cable to serial portTable 3: Settings for connecting USB cable to serial port
SpecificationsSpecifications ValueValue
Baud rate 115200
Data bits 8
Parity None
Stop bit 1 (8 N1)
Flow control XON/XOFF
ProcedureProcedure
1. Power down the blade.
2. Connect the USB-to-serial cable to the system. The USB end is connected to a system USB port.
3. Attach the serial end of the cable to a serial port using a null modem cable. The other serial port may be another USB-to-serial
adapter on a different machine.
4. Power on the blade. The serial console output screen displays.
5. Press the ESCESC + 99 keys. The System Utilities menu displays.
