Shock and vibration specificationsShock and vibration specifications

SpecificationSpecification ValueValue

Operational shock 30 g peak, half-sine, 11 ms pulse

Random vibration 5 Hz to 500 Hz, 0.3 g rms

Shock and vibration specifications 151
