6. Remove the server access panel.
Figure 18 Access panel removal
power off the server
WARNING! To reduce the risk of personal injury, electric shock, or damage to the equipment,
remove the power cord to remove power from the server. The front panel Power On/Standby
button does not completely shut off system power. Portions of the power supply and some internal
circuitry remain active until ac power is removed.
NOTE: If installing a hot-plug device, it is not necessary to power off the server.
1. Back up the server data.
2. Shut down the operating system as directed by the operating system documentation.
NOTE: If the operating system automatically places the server in Standby mode, omit the
next step.
3. Press the Power On/Standby button to place the server in Standby mode. When the server
activates Standby power mode, the system power LED changes to amber.
NOTE: Pressing the UID button illuminates the blue UID LEDs on the front and rear panels.
In a rack environment, this feature facilitates locating a server when moving between the front
and rear of the rack.
4. Disconnect the power cords.
The system is now without power.
Remove the server from the rack
To remove the server from an HP, Compaq branded, telco, or third-party rack:
1. power off the server (“power off the server” (page 102)).
2. Extend the server from the rack (“Extend the server from the rack” (page 99)).
3. Disconnect the cabling and remove the server from the rack. For more information, refer to
the documentation that ships with the rack mounting option.
4. Place the server on a sturdy, level surface.
102 Removal and replacement procedures
