Page #93 background imageLoading...
Page #93 background image
Turn off the server power button and unplug the ac power cords and any cables.a.
b. Re-seat all of the SAS disk drives installed in the server.
c. Reconnect the ac power cords and any cables. Restart the server to determine whether
the LEDs now become illuminated during the boot. If not, contact your reseller.
4. Use the UEFI Shell info io command to check the SCSI drives.
System LAN LEDs
There are four system LAN LEDs on the rear bulkhead of the server. These LANs are connected to
the system board.
Table 44 Gb LAN connector LEDs
DescriptionLED
Green: linkLink (left)
Off: no link
Green: linkActivity (right)
Off: No link
Troubleshooting the boot process
Table 45 shows the normal boot process, as reflected in changes to front panel LED states:
Table 45 Normal boot process LED states
Normal power-up through OS bootSIDPowerHealthSystem Event
Log
Step
No ac power to the system.OffOffOffOff1
System is shut down, but ac power
and standby power is active.
OffSteady amberOffOff2
System power rails are on when
power switch is toggled.
OffSteady greenOffOff3
System power rails are on; BMC
drives external health LED.
OffSteady greenSteady greenOff4
System is booting firmware (has
passed BOOT_START in firmware).
OffSteady greenSteady greenOff5
System has finished booting
firmware and an OS is either
booting or running.
OffSteady greenSteady greenSteady green6
NOTE: In the normal boot process, shown in the preceding table, even though the BMC is running
while the system is shut down (power LED is steady amber), it doesn’t drive the external health LED
to steady green until +12 V dc power from the Bulk Power Supplies is applied.
The following list itemizes the steps that characterize basic platform boot flow. Step numbers
provided correspond to the steps in Table 45 (page 93).
3) System power switch turns on bulk power supplies and fans, and releases RESET on all CPUs
simultaneously, when toggled on.
5) Initial CPU firmware code fetch is PAL code from EEPROM in PDH, retrieved 4 bytes at a time
by DMDC in ICH10 (No shared memory or I/O devices are available at this time; for example
they are not initially configured).
Troubleshooting the boot process 93
