2 Server Specifications
This chapter provides the specifications for the server.
For information on general computer room site preparation, see the HP Generalized Site Preparation
Guide on the HP website at:
http://www.hp.com/go/Integrity_Servers-docs
System configuration
Table 9 Hardware specifications for the server
ServerComponent
One or two Itanium dual or quad-core CPUs:
• 1.6-GHz Dual-core CPU 10-MB cache
• 1.46-GHz Quad-core CPU 16-MB cache
• 1.73-GHz Quad-core CPU 20-MB cache
CPUs
Supports up to twenty-four Double Data Rate 3 (DDR3) DIMMs mounted on risers that attach
to the system board.
Supported DIMM sizes are as follows:
• 2 GB
• 4 GB
• 8 GB
(future release)
• 16 GB (future release)
Minimum memory configuration is 4 GB (2 x 2-GB DIMMs).
Maximum memory configuration is 96 GB (24 x 4 GB DIMMs).
1
Memory
One to eight hot plug SAS hard drives.Disk drives
I/O riser options:
• one full height full length PCIe x8 and two low profile PCIe x4 slots
• one full height full length PCIe x8 and one low profile PCIe x8 slots
PCI slots
Eight port SAS core I/O card or eight port SAS core I/O card with internal RAID.SAS core I/O
Four GigE LAN ports.LAN core I/O
One serial port, four USB 2.0 ports, one 1G/100/10 LAN port, and twol VGA ports.Management core I/O
One SATA DVD+RW drive.Optical drive
One 800 watt (@120 V ac) or 1200 watt (@240 V ac) power supply, 1+1 redundancy with
the second power supply.
IMPORTANT: 800 W redundancy does not apply to all configurations.
Power supply
1 384 GB (24 x 16 GB DIMMs) future release
Dimensions and weight
Table 10 Rack or pedestal-mounted server dimensions
ValueDimensions and weight
Data Center Server Dimensions
68.8 cm (27.1 in)Depth
22 Server Specifications
