Cooling subsystem
Six fans cool the server. The fans are all redundant, hot swap capable, and interchangeable. If
one fan unit fails, the others increase speed to compensate for the failure. The fan units are N+1,
meaning that the server has six fan units, but can operate with five fan units running.
Figure 4 Fan identification
The power supplies have built-in fans and are not controlled by the BMC.
Power subsystem
The server supports 1+1 redundant power supply for high line (1200W/200~240VAC) and low
line (800W/100~120VAC) in the data center and office friendly server versions. Power redundancy
is identified the following table.
Table 3
Redundancy
Memory Riser
CountDIMM CountCPUVoltage
Power Supply
Count
No1 to 424 or less1 or 2High Line
(200-240)
1
Yes1 to 424 or less1 or 2High Line
(200-240)
2
No1 or 212 or less1Low Line
(100-120)
1
Yes1 or 212 or less1Low Line
(100-120)
2
Impossible
configuration
1 or 212 or less1Low Line
(100-120)
1
Impossible
configuration
1 or 212 or less1Low Line
(100-120)
2
No1 or 28 or less2Low Line
(100-120)
1
Yes1 or 28 or less2Low Line
(100-120)
2
14 Overview
