21
Power supply bay 1Power supply bay 2
CAUTION: Observe all ESD safety precautions before attempting this procedure. Failure to follow
ESD safety precautions can result in damage to the server.
CAUTION: If you do not purchase a second power supply, the empty power supply slot must
remain covered with the supplied power supply blank. Failure to observe this caution can result in
server shutdown due to overheating.
NOTE: The power supply is a hot-swappable device. You need not interact with the operating
system to add a power supply to the server.
1. Remove the power supply blank.
2. Install the power supply.
Removing the access panel
1. Use the T-15 Torx screwdriver attached to the rear of the server to loosen the security screw
on the hood latch.
2. Lift the hood latch handle, and then remove the access panel.
30 Installing the server
