Figure 3 Internal USB location
I/O subsystem
The I/O subsystem consists of the core I/O and two optional I/O riser boards. Wake on LAN is
not enabled on any PCIe Public slots. The server does not support PCI Hot Plug (PHP).
The standard I/O Riser supports one full-height, full-length PCIe x8 and two full-height, half-length
PCIe x4 add-in cards. The other riser option when loaded in the primary position has a
iLO/RMII/NC-SI connector to use with certain NIC add-in cards that allow iLO sideband
connections. This second riser option supports one full-height, full-length PCIe x8, and one full-height,
half-length PCIe x8 add-in cards.
NOTE: All PCIe x8 slots are electrically connected as x8 slots but are physically loaded with x16
connectors.
The secondary I/O riser position can either be a riser that supports one full-height, full-length PCIe
x8 and two low-profile PCIe x4 add-in cards or a riser that supports one full-height, full-length PCIe
x8 and one low profile PCIe x8.
Table 2 PCI slot descriptions
2–slot PCIe riser3–slot PCIe riser
Primary riser connector
PCIe2 x16 (8, 4, 2, 1)PCIe2 x16 (8, 4, 2, 1)1 — full length, full height
PCIe2 x16 (8, 4, 2, 1)PCIe2 x8 (4, 2, 1)2 — half length, full height
—PCIe2 x8 (4, 2, 1)3 — half length, full height
Secondary riser connector
PCIe2 x16 (8, 4, 2, 1)PCIe2 x16 (8, 4, 2, 1)4 — full length, full heigth
PCIe2 x16 (8, 4, 2, 1)PCIe2 x8 (4, 2, 1)5 — low profile
—PCIe2 x8 (4, 2, 1)6 — low profile
12 Overview
