HP Integrity rx2800 - i2 - Page 91

Table 42 I/O card events that may light SID LEDs
NotesSourceCauseSample IPMI EventsDiagnostic
LEDs
Disallow O/S
boot and display
the following
UEFI error
message, “I/O
configuration
exceed”
SFWA non hot plug I/O
slot power
consumption increases
the total I/O power
consumption beyond
the supported limit
Type E0h, 4658d:26d
IO_PCI_POWER_OVERLOAD_ERR
I/O Card
Display UEFI
warning message
“Failed I/O slots
deconfigured”
SFWInsufficient power to
power on a hot-plug
PCI-X slot
Type E0h, 137d:26d
IO_NOT_ENOUGH_POWER_ERROR
I/O Card
Either a card /
slot problem.
Re-seat card first.
SFWPCI slot standby
power failed
Type E0h, 147d:26d
IO_SLOT_STANDBY_POWER_ERROR
I/O Card
Either a card /
slot problem.
Re-seat card first.
SFWPCI-X hot-plug
controller failed
Type E0h, 131d:26d
IO_HOT_PLUG_CTRL_FAILED
I/O Card
Remove any
unsupported I/O
cards. Move I/O
card to an
unused PCI slot
SFWPCI bus walk (I/O
discovery) resources
exceeded
Type E0h, 139d:26d
IO_PCI_MAPPING_TOO_BIG
I/O Card
SFWFound invalid
PCIXCAP value
Type E0h, 148d:26d
IO_UNKNOWN_PCIXCAP_VAL
I/O Card
SFWPCIXCAP sampling
error
Type E0h, 141d:26d
IO_PCIXCAP_SAMPLE_ERROR
I/O Card
SFWExpected I/O host
bridge (Lower Bus
Adapter) is missing
Type E0h, 123d:26d
IO_CHECK_LBA_MISSING_ERR
I/O Card
SFWExpected I/O host
bridge (Lower Bus
Adapter) is
deconfigured
Type E0h, 619d:26d
IO_CHECK_LBA_DECONFIG_ERR
I/O Card
SFWI/O LBA clear error
failed
Type E0h, 133d:26d
IO_LBA_CLEAR_ERR_FAILED
I/O Card
SFWI/O SBA clear error
failed
Type E0h, 144d:26d
IO_SBA_CLEAR_ERR_FAILED
I/O Card
SFWPCI-X slot power on
error
Type E0h, 146d:26d
IO_SLOT_POWER_ON_ERROR
I/O Card
SFWPCI-X slot has incorrect
default power state
Type E0h, 145d:26d
IO_SLOT_POWER_DEFAULT_ERROR
I/O Card
SFWI/O host bridge
(Lower Bus Adapter) is
inaccessible because
rope reset failed to
complete
Type E0h, 136d:26d
IO_LBA_RESET_ERROR
I/O Card
Troubleshooting the I/O 91
