HP integrity rx2800 i4 User Manual

4. Disconnect the power cord (see 1 below).
5. Rotate the processor locking handle up and back until it reaches a hard stop (see 2 below).
WARNING! The heat sink locking lever can constitute a pinch hazard, keep your hands on
top of the lever during installation to avoid personal injury.
6. Pull both plastic tabs out (see 3 below).
7. Lift the processor and heat sink off of the socket, pulling straight up.
HP Confidential118 Removal and replacement procedures

HP integrity rx2800 i4 Specifications

General

Number of Processors	1 or 2
Memory Slots	24 DIMM slots
Processor Cores	4 or 8 per processor
Cache	32 MB L3 per processor
Memory	Up to 384 GB DDR3
Storage	Up to 8 SFF SAS/SATA drives
RAID Support	RAID 0, 1, 5, 6
Network	Integrated 10/100/1000Base-T Ethernet
Network Controller	HP NC382i
Expansion Slots	6 PCIe 2.0 slots
Power Supply	Hot-plug redundant power supplies
Operating Systems	HP-UX, Linux
Form Factor	2U Rack
Processor Speed	1.73 GHz, 2.13 GHz, or 2.53 GHz
