253
[RouterA-GigabitEthernet2/1/1] ipv6 pim dm
[RouterA-GigabitEthernet2/1/1] quit
[RouterA] interface gigabitethernet 2/1/2
[RouterA-GigabitEthernet2/1/2] ipv6 pim dm
[RouterA-GigabitEthernet2/1/2] quit
[RouterA] interface tunnel 0
[RouterA-Tunnel0] ipv6 pim dm
[RouterA-Tunnel0] quit
# On Router C, enable IPv6 multicast routing.
[RouterC] ipv6 multicast routing
[RouterC-mrib6] quit
# Enable MLD on GigabitEthernet 2/1/1 (the interface that connects to the receiver host).
[RouterC] interface gigabitethernet 2/1/1
[RouterC-GigabitEthernet2/1/1] mld enable
[RouterC-GigabitEthernet2/1/1] quit
# Enable IPv6 PIM-DM on the other interfaces.
[RouterC] interface gigabitethernet 2/1/2
[RouterC-GigabitEthernet2/1/2] ipv6 pim dm
[RouterC-GigabitEthernet2/1/2] quit
[RouterC] interface tunnel 0
[RouterC-Tunnel0] ipv6 pim dm
[RouterC-Tunnel0] quit
Verifying the configuration
# Send an MLD report from Receiver to join the IPv6 multicast group FF1E::101. (Details not shown.)
# Send IPv6 multicast data from Source to the IPv6 multicast group FF1E::101. (Details not shown.)
# Display PIM routing table information on Router C.
[RouterC] display ipv6 pim routing-table
Total 1 (*, G) entry; 1 (S, G) entry
(*, FF1E::101)
Protocol: pim-dm, Flag: WC
UpTime: 00:04:25
Upstream interface: NULL
Upstream neighbor: NULL
RPF prime neighbor: NULL
Downstream interface(s) information:
Total number of downstreams: 1
1: GigabitEthernet2/1/1
Protocol: mld, UpTime: 00:04:25, Expires: -
(1001::100, FF1E::101)
Protocol: pim-dm, Flag: ACT
UpTime: 00:06:14
Upstream interface: Tunnel0
Upstream neighbor: FE80::A01:101:1
RPF prime neighbor: FE80::A01:101:1
