Extending a VLS Node from the Rack
WARNING!
To reduce the risk of personal injury or equipment damage, be sure that the rack is adequately
stabilized before extending a node from the rack.
WARNING!
Be careful when pressing the rail-release levers and sliding the component into or out of the rack. The
sliding rails could pinch your fingertips.
To extend a node from the rack:
1. Loosen the thumbscrews that secure the node faceplate to the front of the rack.
2. Extend the node on the rack rails until the node rail-release latches engage.
3. After performing the replacement procedure, slide the node back into the rack:
a. Press the node rail-release latches and slide the node fully into the rack.
b. Secure the node by tightening the thumbscrews.
Removing a VLS Node from the Rack
To remove the node from a rack:
1. Power off the node. See Powering Off the System.
2. Disconnect the cabling.
3. Extend the node from the rack. See Extending the Node from the Rack.
4. Remove the node from the rack. For more information, refer to the documentation that ships with
the rack mounting option.
5. Place the node on a sturdy, level surface.
Removing the VLS Node Access Panel
WARNING!
Pressing the Power on/Standby button sets the node to the standby position, which removes power
from most areas of the node. However, portions of the power supply and some internal circuitry
remain active until the AC power cord is removed.
WARNING!
To reduce the risk of personal injury from hot surfaces, allow the internal system components to cool
before touching them.
HP StorageWorks 12000 Gateway Virtual Library System User Guide 197
