Power switch cable assembly
This section describes how to remove and install the power switch cable assembly.
Removing the power switch cable assembly
1. Disconnect power from the workstation (see Predisassembly procedures on page 73).
2. Remove the side access panel (see
Removing the side access panel on page 75).
3. Remove the right side panel (see
Removing the right side panel on page 78).
4. Remove the upper front bezel (see
Removing the upper front bezel on page 83).
5. Remove the screw from the power switch cable assembly as shown in the following figure.
Figure 5-17 Removing the power switch cable assembly
88 Chapter 5 Replacing components ENWW
