Page #225 background image
C Routine Care
General cleaning safety precautions
Never use solvents or flammable solutions to clean the workstation.
Never immerse any component in water or cleaning solutions; apply any liquids to a clean cloth
and then use the cloth on the component.
Always unplug the workstation before cleaning the keyboard, mouse, or air vents.
Always disconnect the keyboard before cleaning it.
Wear safety glasses equipped with side shields when cleaning the keyboard.
Cleaning the workstation case
Follow the safety precautions presented (
Service considerations on page 64) before cleaning the
workstation.
To remove light stains or dirt, use plain water with a clean, lint-free cloth or swab.
For stronger stains, use a mild dish washing liquid diluted with water. Rinse well by wiping it with
a cloth or swab dampened with clear water.
For stubborn stains, use isopropyl (rubbing) alcohol. No rinsing is required because the alcohol
evaporates quickly and does not leave a residue.
After cleaning, always wipe the workstation with a clean, lint-free cloth.
Occasionally, clean the air vents on the workstation. Lint and other foreign matter can block the
vents and limit the airflow.
Cleaning the keyboard
CAUTION: Use safety glasses equipped with side shields before attempting to clean debris from under
the keys.
Follow the safety precautions presented (
Service considerations on page 64) before cleaning the
workstation.
Visible debris underneath or between the keys can be removed by vacuuming or shaking.
Canned, pressurized air can be used to clean debris from under the keys. Use caution because
too much air pressure can dislodge lubricants applied under the wide keys.
If you remove a key, use a specially designed key remover to prevent damage to the keys. This
tool is available from many electronic supply outlets.
CAUTION: Never remove a wide key (like the space bar key) from the keyboard. If these keys
are improperly removed or installed, the keyboard might not function properly.
ENWW General cleaning safety precautions 213

Table of Contents

Other manuals for HP Z600

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Z600 and is the answer not in the manual?

HP Z600 Specifications

General IconGeneral
Tcase76 °C
Bus typeQPI
SteppingD0
FSB ParityNo
Processor cache4 MB
Processor cores4
Processor modelE5504
System bus rate4.8 GT/s
Processor seriesIntel Xeon 5500 Series
Processor socketSocket B (LGA 1366)
Processor codenameNehalem EP
Number of QPI links2
Processor frequency2 GHz
Processor cache typeSmart Cache
Processor lithography45 nm
Processor system typeDP
Processor manufacturerIntel
Processor front side bus- MHz
Processor operating modes64-bit
ECC supported by processorYes
Thermal Design Power (TDP)80 W
Number of processors installed1
CPU multiplier (bus/core ratio)15
Memory types supported by processorDDR3-SDRAM
Memory clock speeds supported by processor800 MHz
Memory bandwidth supported by processor (max)19.2 GB/s
Maximum internal memory supported by processor144 GB
Audio systemIntegrated High Definition Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Product typeWorkstation
Motherboard chipsetIntel® 5520
Internal memory1 GB
Memory channelsTriple-channel
Memory clock speed1333 MHz
Maximum internal memory24 GB
Memory layout (slots x size)1 x 1 GB
HDD speed7200 RPM
HDD capacity250 GB
HDD interfaceSATA
Optical drive typeDVD Super Multi
I/O portsFront: 3 USB 2.0, 1 microphone in, 1 headphone out, optional 1 IEEE 1394a; Rear: 6 USB 2.0, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 1 RJ-45 to integrated Gigabit LAN, optional 1 serial; Internal: 3 USB 2.0
Serial ports quantity0
USB 2.0 ports quantity9
Power supply650 W
DisplayHP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch widescreen), HP LP3065 30-inch Widescreen LCD Monitor (all sold separately)
Drive bays2 external 5.25\
Graphics card-
Keyboard typeHP PS/2 Standard Keyboard
Expansion slots2 PCI Express Gen2 x16, 1 PCI Express Gen2 (x8 mechanically, x4 electrically), 1 PCI Express Gen1 (x8 mechanically, x4 electrically), 2 PCI
Pointing deviceHP USB Laser Scroll Mouse
Power requirements650 watts wide-ranging, active Power Factor Correction, 85% efficient Power Supply
Storage drive type250 GB 7200 rpm SATA NCQ SATA 250 GB
HDD controller typeSATA (10000 rpm) SATA (7200 rpm) SAS (15000 rpm)
Video card featuresNo integrated Graphic Card
Maximum HDD capacity600 GB
Storage drive controllerIntegrated 6 channel SATA 3 Gb/s controller with RAID (0, 1, 5 or 10) capability, optional SAS controller, LSI 3041E 4-port SAS/SATA, with RAID (0, 1 or 10) capability
Minimum storage drive space146 GB
Non-operating altitude9100 m
Storage temperature (T-T)-40 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)8 - 90 %
Operating relative humidity (H-H)8 - 85 %
Operating system installedWindows Vista Business
Compatible operating systemsRed Hat Enterprise Linux WS 5 64-bit, Novell Suse SLED 11
Maximum graphics card memory0.032 GB
Chassis typeMini Tower
Country of originChina
Processor codeSLBF9
Processor ARK ID40711
Processor package size42.5 x 45 mm
Weight and Dimensions IconWeight and Dimensions
Depth440 mm
Width165.3 mm
Height445.1 mm
Weight19000 g
