Designator Silk screen Component
P60-P63 P60 - P63
SATA0 - SATA3
SATA Connectors
P66 - P67 P66 - P67
SATA4 - SATA5
SATA Connectors
P70 P70 CPU0 FAN Primary CPU fan header
P71 P71 CPU1 FAN Secondary CPU fan header
P91 P91 MEM FAN Memory fan header
P93 P93 FRNTFAN Front fan header
P94 P94 IOH FAN IOH fan header
P124 P124 HOOD LOCK Side access panel solenoid lock header
XBT1 XBT1 Battery holder
XMM1 - XMM6 XMM1 - XMM6
DIMM1 - DIMM6
Memory slots
XU1 XU1 CPU0 Primary CPU socket
XU2 XU2 CPU1 Secondary CPU socket
212 Appendix B System board designators ENWW
