HP Z600

Lower front bezel
This section describes how to remove and install the lower front bezel.
Removing the lower front bezel
1. Disconnect power from the workstation (see Predisassembly procedures on page 73).
2. Remove the side access panel (see
Removing the side access panel on page 75).
3. Remove the right side panel (see
Removing the right side panel on page 78).
4. Remove the two lower front bezel screws from the bottom of the chassis as shown in the following
figure.
Figure 5-12 Removing the lower front bezel
5. Rotate the bezel out and upward on the chassis to remove it.
Installing the lower front bezel
To install the lower front bezel, place the bezel on the chassis and install the screws.
