Side access panel solenoid lock
The side access panel solenoid lock provides a method to lock the side access panel by means of a
local or remote signal-controlled solenoid.
This section describes how to remove and install the side access panel solenoid lock.
Removing the side access panel solenoid lock
1. Power down the workstation and remove the side access panel (see Removing the side access
panel on page 75).
2. Lift the rear edge of the top panel, slide it back (to the rear of the system), and then remove.
TIP: There is an indent in the ribbing where you can use a finger to lift the rear edge.
Figure 5-4 Removing the top panel
76 Chapter 5 Replacing components ENWW
