Optical disk drive
This section describes how to remove and install an optical disk drive.
Removing an optical disk drive from the optical bay
1. Disconnect power from the workstation (see Predisassembly procedures on page 73).
2. Remove the side access panel (see
Removing the side access panel on page 75).
3. Disconnect the power
and data
2
cables from the optical disk drive as shown in the following
figure.
Figure 5-22 Disconnecting optical disk drive cables
92 Chapter 5 Replacing components ENWW
