HP Z600

Power supply currents
Table 1-6 Maximum current per rail
Voltage rail 650W maximum
continuous current
+12 V-CPU0 14.0A
+12 V-CPU1 14.0A
+12 V-M 18.0A
+12 V-B 18.0A
+12 V-D 18.0A
+12 V-S 18.0A
V12N 0.15A
+5 V-SB 3.0A
CAUTION: Do not exceed 650 watts of total continuous output power.
Do not exceed 54.2A (650W) of 12V (CPU0/CPU1/M/B/DG/S) power combination.
