Power supply specifications
Table 1-7 Power supply specifications
Item Description
Power supply 650W Wide Ranging, Active PFC
Operating voltage range 90 – 269 VAC
Rated voltage range 100–240 VAC 118 VAC
Rated line frequency 50–60 Hz 400 Hz
Operating line frequency range 47–66 Hz 393–407 Hz
Rated input current 10.0A @ 100-127 VAC
6.0A @ 200–240 VAC
10.0A @ 118 VAC
Heat dissipation
(Configuration and software dependent)
Typical 1578 Btu/hr = (397.7 kg-cal/hr)
Maximum 2705 Btu/hr = (681.8 kg-cal/hr)
Power supply fan Two fans, 60mm x 25mm, variable speed
ENERGY STAR Qualified (configuration
dependent)
Yes
80 Plus compliant 80 Plus Bronze compliant
FEMP Standby Power compliant @115V
(<2W in S5 – Power Off)
Yes
EuP compliant @ 230V (<1w in S5 -- Power
Off)
Yes
Power Consumption in sleep mode (as
defined by ENERGY STAR) - Suspend to
RAM (S3) (Instantly Available PC)
<9 watts
Built-in Self Test LED Yes
Surge Tolerant Full Ranging Power Supply
(withstands power surges up to 2000V)
Yes
Power consumption and heat dissipation
Power consumption and heat dissipation specifications are available for multiple configurations. To
review available specifications, see
http://www.hp.com/go/quickspecs.
To reach zero power consumption, unplug the workstation from the power outlet or use a power strip
with an on/off switch. For additional information about power-saving features, see the operating system
installation instructions.
See the Site preparation guide for the HP
600 Workstation at http://hp.com/support/
workstation_manuals for further power consumption information.
This product is in compliance with U.S. Executive Order 13221.
ENWW Specifications 11
