Page #169 background imageLoading...
Page #169 background image
Active Chat enables you to electronically submit a support ticket to HP over the Web. When you submit
a support ticket, Active Chat collects information about the computer and pass it to an online support
specialist. The collection of information might take up to 30 seconds depending on the computer
configuration. When you submit a support ticket, you receive a confirmation message containing your
case ID, the support hours for your location, and the estimated time of response.
For more information about HP Instant Support and Active Chat and how to use them, visit
http://www.hp.com/hps/hardware/hw_professional.html.
NOTE: This feature is not available on Windows XP Professional x64 Edition or on Linux.
Customer Advisories, Customer and Security Bulletins, and Customer Notices
To find advisories, bulletins, and notices:
1. Visit
http://www.hp.com/go/workstationsupport.
2. Select the desired product.
3. Under Resources for <your selected product>, select See more….
4. Under Self-Help resources: in the center of the window, choose the desired action and appropriate
information in the scroll list to view the index.
Product Change Notifications
Product Change Notifications (PCNs) are proactive notifications for product changes occurring within a
30-60 day window of the effective date of the change in the manufacturing process. PCNs give
customers advanced notice of changes to their product, such as an updated BIOS version that they may
need to qualify prior to the change taking place. The latest PCNs are located at:
http://www.hp.com/go/
workstationsupport.
Helpful hints
If you encounter a problem with the workstation, monitor, or software, the following provides a list of
general suggestions that help you isolate and focus on the problem before taking further action.
At startup
Verify that the workstation and monitor are plugged into a working electrical outlet.
Remove all diskettes, optical disks, and USB drive keys from the drives before powering on the
workstation.
Verify that the workstation is turned on and the green power light is on.
If you have installed an operating system other than the factory-installed operating system, check
to be sure that it is supported on your system by visiting
http://www.hp.com/go/quickspecs.
Verify that the monitor is turned on and the green monitor light is on.
Turn up the brightness and contrast controls of the monitor if the monitor is dim.
If the workstation has multiple video sources and only a single monitor, the monitor must be
connected to the source selected as the primary VGA adapter. During startup, the other monitor
connectors are disabled; if the monitor is connected to one of these ports, it will not function after
Power-on Self Test (POST). You can select the default VGA source in Computer Setup (F10).
ENWW HP troubleshooting resources and tools 157

Table of Contents

Other manuals for HP Z600

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Z600 and is the answer not in the manual?

HP Z600 Specifications

General IconGeneral
Tcase76 °C
Bus typeQPI
SteppingD0
FSB ParityNo
Processor cache4 MB
Processor cores4
Processor modelE5504
System bus rate4.8 GT/s
Processor seriesIntel Xeon 5500 Series
Processor socketSocket B (LGA 1366)
Processor codenameNehalem EP
Number of QPI links2
Processor frequency2 GHz
Processor cache typeSmart Cache
Processor lithography45 nm
Processor system typeDP
Processor manufacturerIntel
Processor front side bus- MHz
Processor operating modes64-bit
ECC supported by processorYes
Thermal Design Power (TDP)80 W
Number of processors installed1
CPU multiplier (bus/core ratio)15
Memory types supported by processorDDR3-SDRAM
Memory clock speeds supported by processor800 MHz
Memory bandwidth supported by processor (max)19.2 GB/s
Maximum internal memory supported by processor144 GB
Audio systemIntegrated High Definition Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Product typeWorkstation
Motherboard chipsetIntel® 5520
Internal memory1 GB
Memory channelsTriple-channel
Memory clock speed1333 MHz
Maximum internal memory24 GB
Memory layout (slots x size)1 x 1 GB
HDD speed7200 RPM
HDD capacity250 GB
HDD interfaceSATA
Optical drive typeDVD Super Multi
I/O portsFront: 3 USB 2.0, 1 microphone in, 1 headphone out, optional 1 IEEE 1394a; Rear: 6 USB 2.0, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 1 RJ-45 to integrated Gigabit LAN, optional 1 serial; Internal: 3 USB 2.0
Serial ports quantity0
USB 2.0 ports quantity9
Power supply650 W
DisplayHP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch widescreen), HP LP3065 30-inch Widescreen LCD Monitor (all sold separately)
Drive bays2 external 5.25\
Graphics card-
Keyboard typeHP PS/2 Standard Keyboard
Expansion slots2 PCI Express Gen2 x16, 1 PCI Express Gen2 (x8 mechanically, x4 electrically), 1 PCI Express Gen1 (x8 mechanically, x4 electrically), 2 PCI
Pointing deviceHP USB Laser Scroll Mouse
Power requirements650 watts wide-ranging, active Power Factor Correction, 85% efficient Power Supply
Storage drive type250 GB 7200 rpm SATA NCQ SATA 250 GB
HDD controller typeSATA (10000 rpm) SATA (7200 rpm) SAS (15000 rpm)
Video card featuresNo integrated Graphic Card
Maximum HDD capacity600 GB
Storage drive controllerIntegrated 6 channel SATA 3 Gb/s controller with RAID (0, 1, 5 or 10) capability, optional SAS controller, LSI 3041E 4-port SAS/SATA, with RAID (0, 1 or 10) capability
Minimum storage drive space146 GB
Non-operating altitude9100 m
Storage temperature (T-T)-40 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)8 - 90 %
Operating relative humidity (H-H)8 - 85 %
Operating system installedWindows Vista Business
Compatible operating systemsRed Hat Enterprise Linux WS 5 64-bit, Novell Suse SLED 11
Maximum graphics card memory0.032 GB
Chassis typeMini Tower
Country of originChina
Processor codeSLBF9
Processor ARK ID40711
Processor package size42.5 x 45 mm
Weight and Dimensions IconWeight and Dimensions
Depth440 mm
Width165.3 mm
Height445.1 mm
Weight19000 g
