Front panel components
The following figure shows the front panel of a typical workstation configuration.
Figure 1-3 Front panel
Table 1-2 Front panel connectors
*
Item Symbol Description Item Symbol Description
1 Workstation power button/power on
light
6 Headphone connector
2 Hard disk drive activity light 7 Microphone connector
3 Optical disk drive 8 Optional IEEE-1394 connector
(optional, and plugged unless
configured)
4 Optical disk drive eject button 9 Optical disk drive activity light
5 USB 2.0 connectors (3) 10 5.25-inch drive bay
*
Refer to the Maintenance and Service Guide for the workstation for specific front panel connector information.
