Screen message Probable cause Recommended action
925—Fatal error on IOH
miscellaneous
Fatal miscellaneous error detected on
IOH core x, where x is 0 or 1.
Potential system board problem; contact HP Support.
926—Fatal error on IOH Vtd Fatal error detected in the Intel
Virtualization Technology.
Potential system board problem; contact HP Support.
927—Fatal error on DIMM in
slot CPU X DIMM Y
Fatal multibit ECC error detected on
the DIMM in the slot labeled CPU x
DIMM y (where x is 0 or 1 and y is 1 -
6), as labeled on the system board.
Replace the DIMM in the identified slot.
928—Fatal machine check
detected on CPU X
Contact HP support.
1720—SMART Hard Drive
Detect Imminent Failure
Hard drive is about to fail. (Some hard
disk drives have a firmware patch that
fixes erroneous error messages.)
1. Determine if the hard disk drive is giving a correct
error message.
2. Run the Drive Protection System test (if
applicable).
3. Apply firmware patch (if applicable).
See
http://www.hp.com/support.
4. Back up contents and replace the hard disk drive.
1783—Fixed Disk 0/1 locked Hard disk drive failure. Diagnose the hard disk drive, and replace it if
necessary.
1796—SATA Cabling Error Missing or improperly attached cable. Verify that a cable is attached. Reattach the cable.
1797—SATA Drivelock is not
supported in RAID mode
STAT Drivelock is not supported in
RAID mode.
Disable RAID mode, or disable SATA drivelock.
1801—Microcode Update
Error
Unsupported processor (C0 Stepping
or greater only).
The microcode update failed. Check the processor
stepping to ensure it is a supported stepping. If it is
contact, HP Support.
1802—Processor Not
Supported
The system board does not support the
processor.
Replace the processor with a compatible one.
1803—Processor feature set
is insufficient for current
system settings
Processor feature set is insufficient for
current system settings. The BIOS
settings do not match the support
provided by the processor
Change the BIOS settings or upgrade the processors.
1804—A processor feature
and the memory configuration
are incompatible
A processor feature is incompatible
with the memory configuration.
Restore the previous memory configuration.
ERROR: Invalid 1394 GUID
(Invalid electronic serial
number)
No electronic serial number is stored
with the system.
To assign a serial number , select Security >System
IDs in the Computer Setup (F10) Utility.
ERROR: Invalid electronic
serial number (no number)
No electronic serial number is stored
with the system
To assign a serial number , select Security >System
IDs in the Computer Setup (F10) Utility.
ERROR: An unsupported
processor is installed. System
halted
Unsupported processor detected. Replace the processor.
ERROR: A processor requiring
too much power is installed.
System halted
Unsupported processor detected. Replace the processor.
Table 6-10 POST error messages (continued)
186 Chapter 6 Diagnostics and troubleshooting ENWW

HP Z600 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor cache	4 MB
Processor cores	4
Processor model	E5504
System bus rate	4.8 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Number of QPI links	2
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	15
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	800 MHz
Memory bandwidth supported by processor (max)	19.2 GB/s
Maximum internal memory supported by processor	144 GB
Audio system	Integrated High Definition Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Product type	Workstation
Motherboard chipset	Intel® 5520
Internal memory	1 GB
Memory channels	Triple-channel
Memory clock speed	1333 MHz
Maximum internal memory	24 GB
Memory layout (slots x size)	1 x 1 GB
HDD speed	7200 RPM
HDD capacity	250 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
I/O ports	Front: 3 USB 2.0, 1 microphone in, 1 headphone out, optional 1 IEEE 1394a; Rear: 6 USB 2.0, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 1 RJ-45 to integrated Gigabit LAN, optional 1 serial; Internal: 3 USB 2.0
Serial ports quantity	0
USB 2.0 ports quantity	9
Power supply	650 W
Display	HP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch widescreen), HP LP3065 30-inch Widescreen LCD Monitor (all sold separately)
Drive bays	2 external 5.25\
Graphics card	-
Keyboard type	HP PS/2 Standard Keyboard
Expansion slots	2 PCI Express Gen2 x16, 1 PCI Express Gen2 (x8 mechanically, x4 electrically), 1 PCI Express Gen1 (x8 mechanically, x4 electrically), 2 PCI
Pointing device	HP USB Laser Scroll Mouse
Power requirements	650 watts wide-ranging, active Power Factor Correction, 85% efficient Power Supply
Storage drive type	250 GB 7200 rpm SATA NCQ SATA 250 GB
HDD controller type	SATA (10000 rpm) SATA (7200 rpm) SAS (15000 rpm)
Video card features	No integrated Graphic Card
Maximum HDD capacity	600 GB
Storage drive controller	Integrated 6 channel SATA 3 Gb/s controller with RAID (0, 1, 5 or 10) capability, optional SAS controller, LSI 3041E 4-port SAS/SATA, with RAID (0, 1 or 10) capability
Minimum storage drive space	146 GB
Non-operating altitude	9100 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 90 %
Operating relative humidity (H-H)	8 - 85 %
Operating system installed	Windows Vista Business
Compatible operating systems	Red Hat Enterprise Linux WS 5 64-bit, Novell Suse SLED 11
Maximum graphics card memory	0.032 GB
Chassis type	Mini Tower
Country of origin	China
Processor code	SLBF9
Processor ARK ID	40711
Processor package size	42.5 x 45 mm

Weight and Dimensions

Depth	440 mm
Width	165.3 mm
Height	445.1 mm
Weight	19000 g
