HP Z600

SAS drive
Segment Pin Backplane
receptacle
Plug and
cable
receptacles
Power segment
P1
V
33
c
P2
V
33
c
P3
V
33
c
precharge
c
P4 GROUND
P5 GROUND
P6 GROUND
P7
V
5
c
precharge
c
P8
V
5
c
P9
V
5
c
P10 GROUND
P11
READY LED
d
P12 GROUND
P13
V
12
precharge
c
P14
V
12
c
P15
V
12
c
Workstation VGA
Pin Signal Pin Signal Pin Signal
1
2
3
Red Analog
Green Analog
Blue Analog
6
7
8
GND
GND
GND
11
12
13
Monitor ID
DDC Serial Data
Horizontal Sync
4
5
Monitor ID
GND
9
10
+5 VDC
GND
14
15
Vertical Sync
DDC Serial Clock
204 Appendix A Connector pins ENWW
