HP Z600 User Manual

Heading Option Description
Hardware
Power
Management
Enables or disables:
●
SATA Power Management
●
Intel Turbo Boost Technology
●
Enhanced Intel Turbo Boost Technology
●
Eup Compliance Mode
Thermal Enables you to set the rate of the system fan when the CPU is in idle.
Advanced
2
Power-On
Options
Enables you to set the following:
●
POST Messages—Enables or disables the splash screen during POST.
●
F9 Prompt (Displayed or Hidden)—Selecting Displayed displays the F9=Boot Menu during
POST. Selecting Hidden prevents the text from being displayed. However, pressing F9 still
accesses the boot menu.
●
F10 Prompt (Displayed or Hidden)—Selecting Displayed displays F10=Setup during POST.
Selecting Hidden prevents the text from being displayed, but pressing F10 still accesses the
Setup screen.
●
F12 Prompt (Displayed or Hidden)—Selecting Displayed displays F12=Network Service
Boot during POST. Selecting Hidden prevents the text from being displayed but pressing
F12 still forces the workstation to attempt booting from the network.
●
Option ROM
1
prompt (Enable or Disable)—Enabling this feature causes the workstation to
display a message before loading options ROMs.
●
Remote Wakeup Boot Source—Enables you to set the remote wakeup boot source as:
◦
Local Hard Drive
◦
Remote Server
●
After Power Loss (On, Off, Previous State)—Enabling this option directs the previous state
to be the default.
●
POST Delay (in seconds) (5, 10, 15, 20, None)—Adds a specified delay to the POST process.
This delay is sometimes needed for hard disk drives on some expansion cards that spin up
slowly (so slowly that they are not ready to start by the time POST is finished). The POST
delay also gives you time to select F10 to enter the Computer Setup (F10) Utility.
BIOS Power-On Enables you to disable or specify a weekday and time for BIOS power-on.
Processors Enables/disables these options:
●
Hyper-Threading—Provides processor parallelization such that the operating system treats
one processor as two.
●
Active Cores (1,2, or All Cores)—Selects a single core, or multiple cores per socket. (Not
available on some configurations.)
●
Limit CPUID Maximum Value to 3 (Enable or Disable)—Sets the number of allowable CPU
IDs.
Onboard
Devices
Enables you to set resources (IRQ, DMA, I/O Rate) for or disable onboard system devices such
as serial port and diskette controller. Operating system parameters generally override Onboard
Devices settings.
PCI VGA
Configuration
Configures graphics cards per workstation slots. In multi-graphics card configurations, this option
designates one card as primary graphics, and the other card as secondary graphics.
Table 4-1 Computer Setup (F10) Utility menu descriptions (continued)
ENWW The Computer Setup (F10) Utility 39

HP Z600 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor cache	4 MB
Processor cores	4
Processor model	E5504
System bus rate	4.8 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Number of QPI links	2
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	15
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	800 MHz
Memory bandwidth supported by processor (max)	19.2 GB/s
Maximum internal memory supported by processor	144 GB
Audio system	Integrated High Definition Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Product type	Workstation
Motherboard chipset	Intel® 5520
Internal memory	1 GB
Memory channels	Triple-channel
Memory clock speed	1333 MHz
Maximum internal memory	24 GB
Memory layout (slots x size)	1 x 1 GB
HDD speed	7200 RPM
HDD capacity	250 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
I/O ports	Front: 3 USB 2.0, 1 microphone in, 1 headphone out, optional 1 IEEE 1394a; Rear: 6 USB 2.0, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 1 RJ-45 to integrated Gigabit LAN, optional 1 serial; Internal: 3 USB 2.0
Serial ports quantity	0
USB 2.0 ports quantity	9
Power supply	650 W
Display	HP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch widescreen), HP LP3065 30-inch Widescreen LCD Monitor (all sold separately)
Drive bays	2 external 5.25\
Graphics card	-
Keyboard type	HP PS/2 Standard Keyboard
Expansion slots	2 PCI Express Gen2 x16, 1 PCI Express Gen2 (x8 mechanically, x4 electrically), 1 PCI Express Gen1 (x8 mechanically, x4 electrically), 2 PCI
Pointing device	HP USB Laser Scroll Mouse
Power requirements	650 watts wide-ranging, active Power Factor Correction, 85% efficient Power Supply
Storage drive type	250 GB 7200 rpm SATA NCQ SATA 250 GB
HDD controller type	SATA (10000 rpm) SATA (7200 rpm) SAS (15000 rpm)
Video card features	No integrated Graphic Card
Maximum HDD capacity	600 GB
Storage drive controller	Integrated 6 channel SATA 3 Gb/s controller with RAID (0, 1, 5 or 10) capability, optional SAS controller, LSI 3041E 4-port SAS/SATA, with RAID (0, 1 or 10) capability
Minimum storage drive space	146 GB
Non-operating altitude	9100 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 90 %
Operating relative humidity (H-H)	8 - 85 %
Operating system installed	Windows Vista Business
Compatible operating systems	Red Hat Enterprise Linux WS 5 64-bit, Novell Suse SLED 11
Maximum graphics card memory	0.032 GB
Chassis type	Mini Tower
Country of origin	China
Processor code	SLBF9
Processor ARK ID	40711
Processor package size	42.5 x 45 mm

Weight and Dimensions

Depth	440 mm
Width	165.3 mm
Height	445.1 mm
Weight	19000 g
