Example of software upgrade through a reboot
Network requirements
Use the file startup-r3111p02.ipe to upgrade software images for the IRF fabric in Figure 35.
Figure 35 Network diagram
Configuration procedure
# Configure IP addresses and routes to make sure the device and the TFTP server can reach each
other. (Details not shown.)
# Complete TFTP settings on both the device and the TFTP server. (Details not shown.)
# Display information about the current software images.
<Sysname> display version
# Use TFTP to download the image file startup-r3111p02.ipe from the TFTP server to the root
directory of the flash on the master device.
<Sysname> tftp 2.2.2.2 get startup-r3111p02.ipe
# Back up the image file to startup-r3111p02-backup.ipe. Skip this step if the flash does not have
sufficient space.
<Sysname> copy startup-r3111p02.ipe startup-r3111p02_backup.ipe
# Specify startup-r3111p02.ipe as the main startup image file for all IRF member devices.
<Sysname> boot-loader file flash:/startup-r3111p02.ipe slot 1 main
<Sysname> boot-loader file flash:/startup-r3111p02.ipe slot 2 main
# Specify startup-r3111p02-backup.ipe as the backup startup image file for all IRF member
devices.
<Sysname> boot-loader file flash:/startup-r3111p02-backup.ipe slot 1 backup
<Sysname> boot-loader file flash:/startup-r3111p02-backup.ipe slot 2 backup
# Verify the startup image settings.
<Sysname> display boot-loader
# Reboot the device to complete the upgrade.
<Sysname> reboot
# Verify that the device is running the correct software.
<Sysname> display version
TFTP server
2.2.2.2/24
Internet
IRF
1.1.1.1/24
IRF link
Master
(Member ID = 1)
Subordinate
(Member ID = 2)
