Item Description
15 NVMe port 4A
16 NVMe/SATA port 8A
17 NVMe port 5A
18 Front I/O connector
19 Fan connector 8
20 GPU power connector 1
21 Fan connector 7
22 Fan connector 6
23 TPM connector
24 Fan connector 5
25 Fan connector 4
26 NVMe port 3A
27 NVMe port 1A
28 Fan connector 3
29 NVMe port 2A
30 Fan connector 2
31 Fan connector 1
32 Smart Array modular controller connector/NVMe port 7A
33 Drive backplane power connector 3
34 Drive backplane power connector 2
35 Chassis intrusion detection switch connector
36 Drive backplane power connector 1
System maintenance switch descriptions
Position
Default Function
S1
1
O
O = iLO security is enabled.
On = iLO security is disabled.
S2 O Reserved
S3 O Reserved
S4 O Reserved
S5
1
O
O = Power-on password is enabled.
On = Power-on password is disabled.
