HPE ProLiant DL325 Gen10 Plus User Manual

Component identification
Front panel components
LFF drive model
Item Description
1 Optical drive (optional, for short chassis only)
2 Serial label pull tab
3 iLO service port
4 USB 30 port
5 LFF drive bays (up to 12 LFF drives)
SFF SAS/SATA/NVMe drive model
Item
Description
1 Serial label pull tab
2 Optical drive cage (optional, for short chassis only)
3 2SFF SAS/SATA/NVMe drive cage (optional, for short chassis only)
4 2SFF dual uFF M.2 drive cage (optional, for short chassis only)
Table Continued
Component identification 7

HPE ProLiant DL325 Gen10 Plus Specifications

General

Processor Sockets	1
Maximum Processors	1
Memory Slots	16 DIMM slots
Form Factor	1U Rack
Processor	AMD EPYC 7002 and 7003 Series
Memory	Up to 4TB DDR4
Drive Bays	8 SFF or 4 LFF
RAID Support	HPE Smart Array controllers
Network	HPE Ethernet 1Gb 4-port Adapter
Power Supply	800W Platinum, 1600W Platinum
Expansion Slots	3 PCIe 4.0 slots
Operating System Support	Windows Server, VMware
