HPE ProLiant DL325 Gen10 Plus

9. Install the access panel.
10.
Install the inner rack rails.
11.
Install the server into the rack.
12.
Connect all peripheral cables to the server.
13.
Connect each power cord to the server.
14.
Connect each power cord to the power source.
15.
Power up the server.
16.
If removed, install the bezel.
Removing an inner drive cage
Prerequisites
Before you perform this procedure, make sure that you have a T-10 Torx screwdriver available.
Procedure
1.
If installed,
remove the bezel.
2. Power down the server.
3. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
4. Disconnect all peripheral cables from the server.
5.
Remove the server from the rack.
6.
Remove the inner rack rails.
42
Operations
