Procedure
1. If installed, remove the bezel.
2. Power down the server.
3. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
4. Disconnect all peripheral cables from the server.
5.
Remove the server from the rack.
6.
Remove the inner rack rails.
7. Remove the access panel.
8. Do one of the following:
•
Remove the inner drive cage.
• Remove the inner drive cage blank.
9. Remove the outer drive cage cover.
10. Remove the ODD bay blank.
Hardware options installation
93
