Figure 7-6 Locking the front bezel
----End
7.5 Removing a Hard Disk
Remove a hard disk before replacing it with a new one.
You do not need to power off the 5288 V3 before removing a hard disk. If services are
running on the 5288 V3, you have backed up the data stored on the hard disk to be removed.
Before removing a hard disk, determine its location to prevent misoperations. Otherwise, the
RAID array will fail.
NOTE
If a hard disk is frequently removed and installed in an interval shorter than 30 seconds, there are risks
that the hard disk cannot be identified.
Figure 7-7, Figure 7-9, or Figure 7-8 shows the silkscreens of the hard disks on the 5288 V3.
5288 V3 Server
User Guide
7 Replacing Parts
Issue 26 (2018-11-19) Copyright © Huawei Technologies Co., Ltd. 126
