● Material: smart rPDU of the same specications
Context
The smart rPDU is installed near the rear door of the cabinet.
Procedure
Step 1 Open the rear door of the cabinet.
Step 2 Connect the IT load of the faulty smart rPDU to a normal rPDU.
Step 3 Turn o the industrial connector for the faulty smart rPDU. Ensure that the smart
rPDU input has no power.
Step 4 Remove signal cables from the ports on the smart rPDU and label the cables.
Step 5 Remove the screws that secure the smart rPDU using a Phillips screwdriver.
Step 6 Secure the new smart rPDU in the installation position of the old smart rPDU.
Step 7 Connect the input power cables and signal cables to the new smart rPDU.
Step 8 Turn on the upstream power distribution switch for the smart rPDU and the smart
rPDU input switch.
Step 9 Verify that the smart rPDU power output is normal and then connect the IT load
cables to the smart rPDU.
----End
5.2.7 Parts Replacement for the New Main Way
For details about parts replacement for new main way, see the "Parts
Replacement" section in the new main way quick guide.
Table 5-6 Replaceable parts of the new main way
No.
Replaceable Part
1 General Input Unit
2 Power Distribution Unit
3 SPD
4 SPD Circuit Breaker
5 Auxiliary Contact of an SPD Circuit
Breaker
6 Monitoring Board of the General Input
Unit
7 Alarm Indicator
8 Integrated Management Card
FusionModule2000 Smart Modular Data Center
Maintenance Guide (Fusion Module Actuator) 5 Parts Replacement
Issue 01 (2020-12-25) Copyright © Huawei Technologies Co., Ltd. 63
