Figure 5-23 Installing a new hard disk
Step 4 Observe the hard disk indicator to check whether the hard disk works properly.
----End
Follow-up Procedure
If the hard disk works abnormally, contact Huawei technical support.
5.4.2.6 Replacing an IVS1800
Prerequisites
● Recommended tool: Phillips screwdriver
● An IVS1800 needs to be replaced.
● A spare IVS1800 of the same model is available and functional.
Context
Videos cannot be recorded during the replacement of the IVS1800.
Do not operate with power on. Take appropriate insulation measures.
Procedure
Step 1 Turn
o the power switch of the IVS1800, disconnect the power supply of the
IVS1800, remove the cables from the IVS1800, label the cables, and record the
original connection positions of the cables.
FusionModule2000 Smart Modular Data Center
Maintenance Guide (Fusion Module Actuator) 5 Parts Replacement
Issue 01 (2020-12-25) Copyright © Huawei Technologies Co., Ltd. 80
