Parameter Description Conguration Principle
Temp control
mode
Controls the
temperature inside
the room or aisles
based on the
Average,
Maximum, or
Minimum of the
temperatures
collected by each
sensor.
● Average: Select Average if the
temperature is to be controlled based
on the averaged data value collected
by the collector.
● Maximum: Select Maximum if the
temperature is to be controlled based
on the maximum data value collected
by the collector.
● Minimum: Select Minimum if the
temperature is to be controlled based
on the minimum data value collected
by the collector.
Supply-air
temp set point,
Supply-air
humid set
point
Sets the required
humidity and
temperature in a
room or aisle.
The ACC controls the temperature and
humidity based on the set value. For
example, if Temp control type is set to
Return-air, Return-air temp set point
is set to 30.0, and Return-air humid set
point is set to 25.0, the ACC will control
the temperature and humidity around
the return-air vent of the smart cooling
product to a temperature of 30°C and
humidity of 25% RH.
Return-air
temp set point,
Return-air
humid set
point
Cold-aisle
temp set point,
Cold-aisle
humid set
point
Hot-aisle temp
set point, Hot-
aisle humid set
point
Cold aisle
sensor 1, 2, 3
Sets the sensors in
cold aisles to
Enable.
Enable the corresponding humidity and
temperature sensor installed in the cold
aisle.
Hot aisle
sensor 1, 2, 3
Sets the sensors in
hot aisles to
Enable.
Enable the corresponding humidity and
temperature sensor installed in the hot
aisle.
----End
