Temperature
(°C)
Saturation
Pressure-
Surface
Pressure
(MPa)
Temperatur
e (°C)
Saturatio
n
Pressure-
Surface
Pressure
(MPa)
Temperatu
re (°C)
Saturati
on
Pressur
e-
Surface
Pressur
e (MPa)
10 0.99 29 1.74 48 2.83
11 1.02 30 1.79 49 2.9
12 1.05 31 1.84 50 2.97
13 1.09 32 1.89 51 3.04
14 1.12 33 1.94 52 3.11
15 1.16 34 1.99 53 3.19
16 1.19 35 2.04 54 3.26
17 1.23 36 2.1 55 3.34
18 1.27 37 2.15 N/A N/A
3.1.2.2 Refrigerant Oil
The recommended refrigerant oil is Danfoss 160SZ. You can purchase it from
Huawei, or purchase it by yourself after being
conrmed by Huawei.
NO TE
If the low-temperature component is connected, additional refrigerant oil. If not, ignore the
refrigerant oil.
3.1.2.3 Pipe Components
Pipe components are optional and include:
● Liquid pipe: copper pipe (for R410A) external diameter: 5/8 inch; thickness: 1.0
mm; pressure tolerance range: ≥ 4.5 MPa.
● Gas pipe: copper pipe (for R410A) external diameter: 7/8 inch; thickness: 1.2
mm; pressure tolerance range: ≥ 4.5 MPa.
● Thermal insulation foam: thickness ≥ 13 mm.
● Oil traps and inverted traps: To ensure the NetCol5000-A reliability, make an
oil trap every 5 m to 6 m along pipes in the vertical direction and make an
inverted trap respectively at the intake vent and exhaust vent of the outdoor
unit. Figure 3-2 shows the
specications for the oil traps and inverted traps.
