Page #350 background image
NOTE
When the default DIS priority is used,
l The MAC address of the interface on SwitchB is the largest one among that of the interfaces on
the Level-1 Switches. Thus, SwitchB is elected as the Level-1 DIS.
l The MAC address of the interface on SwitchD is the largest one among that of the interfaces on
the Level-2 Switches. Thus, SwitchD is elected as the Level-2 DIS.
The Level-1 pseudonode is 0000.0000.0002.01. The Level-2 pseudonode is 0000.0000.0004.01.
5. Configure the DIS priority of SwitchA.
[SwitchA] interface vlanif 10
[SwitchA-Vlanif10] isis dis-priority 100
[SwitchA-Vlanif10] quit
# Display information about the IS-IS neighbors of SwitchA.
[SwitchA] display isis peer
Peer information for ISIS(1)
----------------------------
System Id Interface Circuit Id State HoldTime Type
PRI
0000.0000.0002 Vlanif10 0000.0000.0001.01 Up 21s L1
(L1L2) 64
0000.0000.0003 Vlanif10 0000.0000.0001.01 Up 27s L1
64
0000.0000.0002 Vlanif10 0000.0000.0001.01 Up 28s L2
(L1L2) 64
0000.0000.0004 Vlanif10 0000.0000.0001.01 Up 30s L2
64
Total Peer(s): 4
6. Verify the configuration.
# Display information about the IS-IS interfaces on SwitchA.
[SwitchA] display isis interface
Interface information for ISIS(1)
---------------------------------
Interface Id IPV4.State IPV6.State MTU Type DIS
Vlanif10 001 Up Down 1497 L1/L2 Yes/Yes
As displayed above, after the DIS priority of the IS-IS interface is changed, SwitchA
immediately becomes a Level-1-2 DIS and its pseudonode is 0000.0000.0001.01.
# Display information about the IS-IS neighbors and IS-IS interfaces on SwitchB.
[SwitchB] display isis peer
Peer information for ISIS(1)
----------------------------
System Id Interface Circuit Id State HoldTime Type
PRI
0000.0000.0001 Vlanif10 0000.0000.0001.01 Up 7s L1
(L1L2) 100
0000.0000.0003 Vlanif10 0000.0000.0001.01 Up 25s
L1 64
0000.0000.0001 Vlanif10 0000.0000.0001.01 Up 7s L2
(L1L2) 100
0000.0000.0004 Vlanif10 0000.0000.0001.01 Up 25s
L2 64
[SwitchB] display isis interface
Interface information for ISIS(1)
---------------------------------
Interface Id IPV4.State IPV6.State MTU Type DIS
Vlanif10 001 Up Down 1497 L1/L2 No/No
# Display information about the IS-IS neighbors and IS-IS interfaces on SwitchD.
[SwitchD] display isis peer
S6700 Series Ethernet Switches
Configuration Guide - IP Routing 6 IS-IS Configuration
Issue 01 (2012-03-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
331
