l 11.3 Configuring a VPN Instance
Data Preparation
To configure a route multi-instance between an MCE and a site, you need the following data.
No. Data
1 Name of the VPN instance
2 (Optional) Destination address of a static route to the site, name of the destination
VPN instance, mask or mask length, next hop IP address, priority of the route, and
description of the route
3 (Optional) RIP process number, address of the network segment where the VLANIF
interface bound to the VPN instance is located, type and process number of the routing
protocol run between an MCE and a PE, cost of the imported route, and name of the
routing policy during route importing
4 (Optional) OSPF process number, router ID of OSPF, area ID of OSPF, address of
the network segment where the VLANIF interface bound to the VPN instance is
located, type and process number of the routing protocol run between an MCE and a
PE, cost of the imported route, metric of the imported route, tag in the external Link
State Advertisement (LSA) of the imported route, and name of the routing policy
during route importing
5 (Optional) IS-IS process number, Network Entity Title (NET) of the IS-IS process,
number of the VLANIF interface bound to the VPN instance, type and process number
of the routing protocol run between an MCE and a PE, type and value of the cost of
the imported route, administrative tag of the imported route, and level of the routing
table for storing the imported route
6 (Optional) Autonomous System (AS) number, IP address of the VLANIF interface
connecting a CE and an MCE, type and process number of the routing protocol run
between an MCE and a PE, Multi-Exit Discriminator (MED) of the imported route,
and name of the routing policy during route importing
11.4.2 (Optional) Configuring a Static Route Between an MCE and
a Site
Context
Do as follows on the MCE.
You need to configure only routing protocols on a device in a site.
Procedure
Step 1 Run the system-view command to enter the system view.
Step 2 Run the ip route-static vpn-instance vpn-source-name destination-address { mask | mask-
length }{ interface-type interface-number [ gateway-address ] | vpn-instance vpn-destination-
S6700 Series Ethernet Switches
Configuration Guide - IP Routing 11 MCE Configuration
Issue 01 (2012-03-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
633

Huawei S1720 Series Specifications

General

Operating Humidity	5% to 95% (non-condensing)
Uplink Ports	4 x GE combo ports
VLANs	4094
Power Supply	AC 100-240V, 50/60Hz
Layer 2 Features	VLAN
Layer 3 Features	Static routing
Management	SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to +70°C
Dimensions (W x D x H)	442 mm x 220 mm x 43.6 mm
