Huawei S1720 Series Configuration Guide

No. Data
2 Address of a peer or name of a peer group
3 Name of the routing policy, sequence number of the node, and matching rule
4 ID of the ACL
5 AS-Path filter
6 IP-Prefix
7 The threshold of the route-limit
9.5.2 Configuring the Route Filtering Policy Globally
By configuring an MBGP routing policy, you can control route exchange with any remote MBGP
peer.
Context
Do as follows on the switch configured with an MBGP peer:
NOTE
The configuration is optional and is applicable to the route exchange with any peer.
Procedure
Step 1 Run:
system-view
The system view is displayed.
Step 2 Run:
bgp as-number
The BGP view is displayed.
Step 3 Run:
ipv4-family multicast
The BGP-IPv4 multicast address family view is displayed.
Step 4 Run:
filter-policy { acl-number | acl-name acl-name | ip-prefix ip-prefix-name } import
MBGP routing policy is configured to filter the received routes.
The parameters of the command are explained as follows:
l acl-number and acl-name acl-name: specifies the address filtering table.
l ip-prefix-name: specifies the address prefix list.
l import: filters the routes sent by any MBGP peer. Only the routes that pass the filtering are
received.
S6700 Series Ethernet Switches
Configuration Guide - IP Routing 9 MBGP Configuration
Issue 01 (2012-03-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
567

Huawei S1720 Series Specifications

General

Operating Humidity	5% to 95% (non-condensing)
Uplink Ports	4 x GE combo ports
VLANs	4094
Power Supply	AC 100-240V, 50/60Hz
Layer 2 Features	VLAN
Layer 3 Features	Static routing
Management	SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to +70°C
Dimensions (W x D x H)	442 mm x 220 mm x 43.6 mm
