Context
Do as follows on the switch configured with an MBGP peer:
NOTE
The configuration is optional. By default, the route filtering policy based on the IP prefix list is not
configured.
Procedure
Step 1 Run:
system-view
The system view is displayed.
Step 2 Run:
bgp as-number
The BGP view is displayed.
Step 3 Run:
ipv4-family multicast
The BGP-IPv4 multicast address family view is displayed.
Step 4 Run:
peer { ipv4-address | group-name } ip-prefix ip-prefix-name { import | export }
The MBGP routing policy based on the IP prefix list is configured to control the route exchange
with a specified remote MBGP peer.
The parameters of the command are explained as follows:
l group-name: specifies an MBGP peer group.
l ipv4-address: specifies the IP address of a remote MBGP peer.
l ip-prefix-name: specifies the IP prefix list.
l import: filters the routes sent by a specified remote MBGP peer or peer group. Only the
routes that pass the filtering are received.
l export: filters the routes sent to a specified remote MBGP peer or peer group. Only the routes
that pass the filtering are sent.
----End
9.5.7 Configuring the Maximum Number of Routes Received from
Peers
You can set the maximum number of routes that can be received from the peer as required and
specify the action of the peer when the number of routes exceeds the threshold.
Context
Do as follows on the switch configured with an MBGP peer:
NOTE
The configuration is optional. By default, the maximum number of routes received from peers is not
configured.
S6700 Series Ethernet Switches
Configuration Guide - IP Routing 9 MBGP Configuration
Issue 01 (2012-03-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
571
