Huawei S1720 Series Configuration Guide

interface GigabitEthernet1/0/1.2
vlan-type dot1q 40
ip binding vpn-instance vpna
ip address 172.19.1.1 255.255.0.0
#
ospf 100 vpn-instance vpna
area 0.0.0.0
network 172.19.0.0 0.0.255.255
#
ospf 200 vpn-instance vpnb
area 0.0.0.0
network 172.18.0.0 0.0.255.255
#
return
NOTE
The following lists only configuration files related to the MCE. For details on configuring BGP or
MPLS IP VPN, refer to manuals of corresponding devices.
l Configuration file of CE3
#
sysname CE3
#
vlan batch 10
#
interface XGigabitEthernet0/0/1
port link-type trunk
port trunk allow-pass vlan 10
#
return
l Configuration file of CE4
#
sysname CE4
#
vlan batch 20
#
interface XGigabitEthernet0/0/1
port link-type trunk
port trunk allow-pass vlan 20
#
return
S6700 Series Ethernet Switches
Configuration Guide - IP Routing 11 MCE Configuration
Issue 01 (2012-03-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
645

Huawei S1720 Series Specifications

General

Operating Humidity	5% to 95% (non-condensing)
Uplink Ports	4 x GE combo ports
VLANs	4094
Power Supply	AC 100-240V, 50/60Hz
Layer 2 Features	VLAN
Layer 3 Features	Static routing
Management	SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to +70°C
Dimensions (W x D x H)	442 mm x 220 mm x 43.6 mm
