Huawei SmartAX MA5608T Hardware Description

Position Description
3.4 Board
Configuration(MA5600T/
MA5603T)
Modified the mapping between some boards and versions.
l 3.21.1 32-Channel
ADSL2+ Service Board
Comparison
l 3.22.1 24-Channel
VDSL2 Service Board
Comparison
l 3.22.3 64-Channel
VDSL2 Service Board
Comparison
Optimized the description.
Updates in Issue 06 (2013-10-30)
Based on issue 05 (2013-09-18), the document is updated as follows:
Position
Description
3.12.1 Comparison Between
SPU Service Processing
Boards
Added the comparison of SPU boards.
4.3 GE Optical/Electrical
Module
Optimized the description.
Updates in Issue 05 (2013-09-18)
Based on issue 04 (2013-09-12), the document is updated as follows:
Position
Description
3 Board Added the boards: H801CKMD, 3.17.4 H802OPGE
Board Description, 3.12.4 H801SPUC Board
Description, 3.24.5 H802SHGM Board Description.
Included the V800R013C10 updates.
Updates in Issue 04 (2013-09-12)
Based on issue 03 (2013-07-25), the document is updated as follows:
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
About This Document
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
ix

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
