Huawei SmartAX MA5608T Hardware Description

Table 1-5 Dimensions and weight of the N66E-18 dual-standard cabinet
Specification Value
Standard compliance
l ETSI side (21-inch): ETSI 300 119-3
l IEC side (19-inch): IEC 60297-3
Weight (empty cabinet) 67.3 kg
Dimensions (W x D x H) 600 mm x 600 mm x 1800 mm
Installation dimensions of the cabinet top Installation interface
l Hole positions: 450 mm x 400 mm (W x
D)
l Nut specifications: six M8 nuts
Installation dimensions of the cabinet
bottom
Installation interface
l Hole positions: 413 mm x 487 mm (W x
D)
l Bolt specifications: four M12 expansion
bolts
Distance between mounting bar holes
l ETSI side: 1 SU = 25 mm
l IEC side: 1 U = 44.45 mm
Available space
l ETSI side: 67 SU
l IEC side: 37 U
Angle opening width
l ETSI side: 500 mm
l IEC side: 450 mm
Fixing centres
l ETSI side: 515 mm
l IEC side: 465 mm
Distance between the installation surface of
the mounting bar and the inner side of the
cabinet door
l ETSI side: 54 mm
l IEC side: 95 mm
NOTE
For cabinet power specifications, see relevant PDB specification requirements.
1.2.3 Configuration (ETSI subrack)
The N66E-18 dual-standard cabinet uses AC or DC power supply. This topic describes the
configurations of MA5600T ETSI subracks in the cabinet.
NOTE
The MA5600T ETSI subrack is installed on the ETSI side of the cabinet.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
1 Cabinet
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
34

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
