1.1.5 Cable Hole
The power cables and subscriber cables are led into the N63E-22 cabinet from the top and the
bottom of the cabinet. This topic describes the positions of cable holes at the top and the
bottom of the N63E-22 cabinet.
The cables of the N63E-22 cabinet can be routed in the overhead cabling mode or the
underfloor cabling mode.
l In the overhead cabling mode, external cables are led into the cabinet through the top of
the cabinet. Figure 1-9 shows the positions of cable holes at the top of the cabinet.
l In the underfloor cabling mode, external cables are led into the cabinet through the
bottom of the cabinet. Figure 1-10 shows the positions of cable holes at the bottom of
the cabinet.
Figure 1-9 Cable holes at the top of the cabinet (top view)
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
1 Cabinet
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
17

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
