Pin Signal Pin Signal Port Pin Signal Pin Signal
11 A 3
4
27 A 42 43 A 42 59 A 58
12 B 28 B 44 B 60 B
13 A 3
3
29 A 41 45 A 41 61 A 57
14 B 30 B 46 B 62 B
15 A 3
2
31 A 40 47 A 40 63 A 56
16 B 32 B 48 B 64 B
3.19.8 H80DCSPE Board Description
H80DCSPE is a 64-port VDSL2&POTS Combo Board with built-in splitter, providing 64
channels of VDSL2 and POTS access services and supporting SuperVector.
Functional Specifications
Please refer to "VDSL2&POTS Combo Board Comparison".
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
